1. Imported dark infrared ceramic heater, fast heating, high efficiency and long life.
2. Built-in temperature test function, easy to detect PCB temperature.
3. Temperature memory function, three-channel setting, fast switching temperature.
4. Sensor closed loop PID control, accurate and stable temperature.
5. It can be used for preheating of circuit boards and other processes that require uniform heating of the whole.
6. With communication interface, it can communicate with other equipment for online control, and it can also be linked with crack soldering station and hot air desoldering station.
model | QUICK 854D |
Work rate | 400W |
Heating area area | 130*130mm |
Heating body material | Ceramic heater |
Temperature Sensor | K-type thermocouple |
temperature range | 50℃ ～ 350℃ |
Thermometer test range | 0 ～ 600℃ |
Use environment temperature | 0 ～ 40℃ |
Temperature stability | ±1℃ |
Dimensions | 270*203*65mm |
weight | about 2.2kg |
