1. Using a special heater, the temperature distribution on the panel surface is even.
2. Sensor closed loop PID control, accurate and stable temperature.
3. Separately control the power supply and heating, and can also display the actual temperature of the preheating plate without heating, which can avoid accidental burns.
4. It can be used for reflow soldering and preheating of some circuit boards, and other processes that require uniform heating of the whole.
5. Anti-static design.

model | QUICK 870D |
power | 800W |
temperature range | 50-350℃ |
Heating plate area | 180*200mm |
Heating plate material | aluminum |
Temperature Sensor | K-type thermocouple |
Ambient temperature | 0-40℃ |
Temperature stability | ±1℃ |
Dimensions | 342*273*67mm |
weight | 约5.1Kg |
